PARTNER AUDREY (A5-1)
Kód: 212/CEL
Procesor: i3 - 7100U
Cena na dotaz
(1 ks)
| 212/I3
45 447,60 Kč
37 560 Kč
bez DPH
Procesor: i5 - 7100U
Cena na dotaz
(1 ks)
| 212/I5
58 341,36 Kč
48 216 Kč
bez DPH
Procesor: Celeron 3965U
Cena na dotaz
(1 ks)
| 212/CEL
39 959,04 Kč
33 024 Kč
bez DPH
Detailní popis produktu
Item |
AUDREY (A5-1) |
||
|---|---|---|---|
| Display (optional Full HD) |
Max Resolution | 1366 x 768 | 1920 x 1080 |
| Size | 15.6″ | 15.6″ | |
| Brightness | 220 nits | 500 nits | |
| Contrast | 500:1 | 1000:1 | |
| Response Time | 8 ms | 25 ms | |
| Viewing Angle | Right 45° Left 45° / Upper 15° Lower 35° | Right 80° Left 80° / Upper 80° Lower 80° | |
| Technology | LCD with LED backlight | LCD with LED backlight | |
| Touch | 10-point PCAP touch | 10-point PCAP touch | |
| System | CPU (fanless) | Skylake CPUs for POS Ready 7, Windows 8.1, Windows 10 IoT, Linux (Ubuntu) Intel® Celeron® 3955U (Skylake), 2.00 GHz, dual core, 2 MB SmartCache Intel® Core™ i3-6100U (Skylake), 2.30 GHz, dual core, 3MB SmartCache Intel® Core™ i5-6300U (Skylake), 2.40 GHz up to 3.00 GHz, dual core, 3 MB SmartCache Kaby Lake CPUs for Windows 10 IoT, Linux (Ubuntu) Intel® Celeron® 3965U (Kaby Lake), 2.20 GHz, dual core, 2 MB SmartCache Intel® Core™ i3-7100U (Kaby Lake), 2.40 GHz, dual core, 3MB SmartCacheIntel® Core™ i5-7300U (Kaby Lake), 2.60 GHz up to 3.50 GHz, dual core, 3 MB SmartCache |
|
| RAM | 2 x 260 pin DDR4 SO-DIMM-2133: 4 GB, 8 GB, 16 GB, 32 GB | ||
| Storage | 1 x M.2 2280 PCIe Gen3.0 x2 SSD (x4 SSD compatible): 128 GB, 256 GB | ||
| I/O Interface | Serial | 2 x Serial ports, RS232 (RJ45), RI/5V/12V selection by BIOS (COM1, COM2) | |
| LAN | 2 x RJ45, IEEE 802.3 10/100/1000 Mbps Ethernet | ||
| USB | 4 x USB 3.0 | ||
| Cash Drawer | 1 x RJ11 | ||
| DC in | 1 x DC 12 V input power-jack | ||
| DC out | 1 x DC 12 V out | ||
| Audio | 1 x Line-out | ||
| Video | 1 x HDMI (up to 4096 x 2304 @24 Hz) 1 x VGA |
||
| Expansion Slot | Internal | 1 x Mini-PCIe (e.g. Wifi card) | |
| Front Camera | Only on a project base available | ||
| Speaker | Power | 1 x 3 Watts | |
| Optional Configuration | Attached Peripherals | PS-103 printer stand Coming soon: 1 x Multi-Readerhousing with MSR and IC Card Reader and (Fingerprint or RFID or i-Button) 1 x Customer Display |
|
| Others
|
Management | Intel AMT and Intel V-Pro (Only support for i5 CPU) | |
| Colors | Black + Silver Grey; Rose Gold + Silver | ||
| VESA Mounting | 75 x 75 | ||
| Material | Aluminum stand and back, plastic frame | ||
| Certifications | CB, EMC (CE, FCC, VCCI, BSMI), BSMI | ||
| Power |
Power Adapter | AC-In 100~240V / DC-Out 12 V, 90 W | |
| Dimensions | w/o stand | 392 mm (W) x 256 mm (H) x 16 mm (D) | |
| with stand | 392 mm (W) x 322 mm (H) x 200 mm (D) | ||
| Weight | w/o stand | 3.3 Kg | |
| with stand | 4.2 Kg | ||
| Environment
|
Operating Temperature | 5°C ~ 40°C | |
| Storage | -15°C ~ 60°C | ||
| Operating Humidity | 15% ~ 80% | ||
| Storage Humidity | 15% ~ 80% | ||
Doplňkové parametry
| Kategorie: | PARTNER klasické terminály |
|---|---|
| Záruka: | 3 roky |
Audrey POS Solution
